CAT® Hydraulic Cylinder Rod Replace with New

Finning Self Service Repair Options

Cat® Hydraulic Cylinder Rods are induction hardened and chromed for superior scratch and dent resistance. Additionally, Cat Hydraulic Cylinder Rods also feature a friction–welded eye joint (1) for maximum durability.

Warning Signs

Watch for these common repair indicators

  • Excessive Drifting
  • Leaking
  • Increased Cycle Times
  • Reduced Cylinder Speed
  • Bent Rod, Scored/Scratched Rod
  • Damaged Cylinder
  • Productivity decreased
  • Contaminated hydraulic oil
  • Damaged hydraulic cylinder seals
  • Hydraulic oil pressure above or below manufacturer recommended specifications

Elements of the Hydraulic Cylinder Rod – Replace With New
Self-Service Option


Recommended Parts List:

  • Hydraulic Cylinder Seal Kit
  • Cat Hydraulic Cylinder Rod assembly
  • Hydraulic Cylinder Cat seal kit
  • New Cat Hydraulic Cylinder
  • Cat Reman Hydraulic Cylinder
  • Kidney Loop/Flush/Change Hydraulic System Fluid
  • S•O•SSM Sampling Kit

Repair Instructions:

Downloadable .PDF with Purchase

Recommended Tooling List:

  • Hydraulic Cylinder Repair Stand(s)
  • Retaining Ring Pliers Lifting Device
  • Lifting Straps
  • Hydraulic Line Contamination Control
    (Caps, Plugs, Pans, etc.)
  • Hydraulic Press/Accessories
  • Bearing Puller(s)
  • Bearing Mount Compound
  • Seal Guide
  • Hydraulic Cylinder Hone
  • Seal Pick
  • Bearing Puller Adapter

Additional Options:

  • Pins
  • New Cat Hydraulic Cylinder
  • Cat Remanufactured Hydraulic Cylinder
  • Kidney Loop/Flush/Change Hydraulic System Fluid
  • New Hydraulic Cylinder Service Bench
  • S•O•S Services

Genuine
CAT Parts

Backed by our standard
Cat warranty

Service
Instructions

Including safety &
cleanliness guidelines

Recommended
Tooling

With option to purchase

Technical
Support

From Finning experts
